Switchcraft

TB3MB

Tini-QG "Mini XLR", 3 Pin Male, Circular Panel Mount - Black Housing

In stock
Drawings:


Buy Now

View More From This Family

Configuration

  • Number of Conductors: 3
  • Product Line: Tini-QG
  • Mounting Type: Panel
  • Gender: Male
  • Contact Size: 24 AWG
  • Termination Style: Solder Cup
  • Contact Plating: Silver
  • Color: Black
  • Locking: Locking
  • Handle Material: Thermoplastic
  • Packaging Type: Bulk
  • Standard Connector Type: Mini-XLR

Electrical

  • Contact Resistance: 0.01 Ohms
  • Dielectric Withstanding Voltage: 250 Volts
  • Insulation Resistance: 510000 MOhms
  • Current Rating: 5 Amps

Mechanical

  • Life Cycle: 2000 Cycles
  • Operating Force: 13 lbs
  • Coupling Locking Style: Button Latch
  • Wire Size: 28 AWG

Environmental

  • Flame Rating: UL 94V-0

Compliance

  • RoHS Compliant: Compliant
  • REACH Compliant: Compliant
  • Brand: Switchcraft

Material

  • Body Material: Copper Alloy
  • Body Plating: Nickel
  • Contact Material: Copper Alloy
  • Insert Material Type: Thermoplastic
  • Terminal Material: Copper Alloy
  • Frame Material: Thermoplastic
