Switchcraft

415

3 Conductors, Two Fingers, Screw Terminal, Handle: Black (Polarized), Screw Part. No. P1382 -- Nut. No. P1389

Out of stock
Drawings:


Buy Now

View More From This Family

Design and material strictly in accordance with Specification MIL-P-642(A), manufacturers trademark (as required in MIL Specification) appears on plug body. Ideal for use in broadcast and recording studios, military, industrial and telephone switchboard applications, instrumentation and telemetry. Individual plugs, featuring one-piece tip rod and one-piece sleeve and plug body, with complete continuity of thermoplastic insulation between plug elements, are placed into handles to provide a double Twin-Plug plug (two electrically-independent 2-conductor plugs spaced .625" center-to-center, with self-alignment feature) with provision for use of Cord Clamp Number S2674. This plug provides two electrically-independent 3-conductor plug fingers spaced on .625" centers. Fingers are insulated from each other and each provides tip, ring and sleeve connections. Black plastic handle is notched to indicate polarity. Accepts standard 6-conductor cables. Handle has provision for use of Cord Clamp, S2674. It has a .25" diameter finger and a .206" diameter finger to provide automatic polarization.

Configuration

  • Number of Conductors: 3
  • Mounting Type: Cord
  • Termination Style: Screw Terminals
  • Contact Plating: Tin
  • Color: Black
  • Sealed: Not Sealed
  • Handle Material: Thermoplastic
  • Packaging Type: Bulk
  • Number of Stations: 2
  • Standard Connector Type: MIL-Type Jacks & Plugs
  • Jack-Plug Type: Plug
  • Special Feature: Smaller Tip for Polarization

Environmental

  • Temperature Range: -55C to +85C
  • Shielding: Unshielded
  • Minimum Temperature: -55 C
  • Maxiumum Temperature: 85 C

Compliance

  • RoHS Compliant: Compliant
  • REACH Compliant: Compliant
  • Brand: Switchcraft

Dimensional

  • Cable Opening: 0.3 in

Material

  • Body Material: Copper Alloy
  • Body Plating: Natural
  • Insert Material Type: Thermoplastic
  • Terminal Material: Copper Alloy Tinnned
  • Sleeve Material: Copper Alloy
