TT96EDACNO

Configuration

• Number of Conductors: 3
• Termination Style: EDAC
• Contact Plating: Gold
• Color: Black
• Packaging Type: Box
• Number of Stations: 96
• Rack Spaces: 1
• Standard Connector Type: TT/Bantam Jacks & Plugs
• Normalling: Full
• Wired: 1
• Front Connector: TT/Bantam
• Rear Connector: 120 Pin EDAC
• Jack Layout: 2x48

Electrical

• Contact Resistance: 0.03 Ohms
• Dielectric Withstanding Voltage: 500 Volts
• Insulation Resistance: 10000 MOhms
• Voltage Rating: 140 Volts
• Current Rating: 0.1 Amps

Mechanical

• Life Cycle: 30000 Cycles
• Operating Force: 7 lbs

Environmental

• Flame Rating: UL 94V-0
• Maxiumum Temperature: 50 C

Compliance

• RoHS Compliant: Compliant
• REACH Compliant: Compliant
• Brand: Switchcraft

Material

• Contact Material: Gold Alloy
• Insert Material Type: Thermoplastic
• Spring Material: Copper Alloy
